CAT® Hydraulic Excavator 374
High production, more durability, and less maintenance are what the 374 Next Generation Excavator will bring to your business.
Share
Overview
High production, more durability, and less maintenance are what the 374 Next Generation Excavator will bring to your business.
-
Net Power - ISO 9249
358 kW -
Engine Model
Cat C15 -
Engine Power - ISO 14396
359 kW -
Bore
137 mm -
Stroke
171 mm -
Displacement
15.2 l -
Swing Drive
20 l -
Ground Clearance
782 mm
-
Main System - Maximum Flow - Implement
896 l/min -
Maximum Pressure - Equipment
37000 kPa -
Maximum Pressure - Equipment - Lift Mode
38000 kPa -
Maximum Pressure - Travel
35000 kPa -
Maximum Pressure - Swing
3500 kPa
-
Swing Speed
6.5 r/min
-
Maximum Swing Torque
298 kN·m
-
Operating Weight
74000 kg
-
Fuel Tank Capacity
920 l -
Cooling System
71 l -
Engine Oil
62 l -
Final Drive - Each
32 l -
Hydraulic System - Including Tank
620 l -
Hydraulic Tank
326 l -
Shipping Length
12978 mm -
Tail Swing Radius
4171 mm -
Counterweight Clearance
1494 mm -
Track Length
5873 mm -
Maximum Reach at Ground Level
11470 mm -
Maximum Cutting Height
11000 mm -
Maximum Loading Height
7050 mm -
Minimum Loading Height
3470 mm -
Maximum Vertical Wall Digging Depth
3710 mm
-
Note
Track gauge undercarriage extended with 650 mm (26") shoes; transport width undercarriage retracted with 650 mm (26") shoes and no steps
-
Stick
M2.57m (8'5") -
Bucket
XD 4.4 m³ (5.75 yd³) -
Shipping Height - Top of Cab
3559 mm -
Handrail Height
3982 mm -
Track Length to Center of Rollers
4705 mm -
Transport Width
3400 mm -
Boom
Mass 7.0m (23) -
Stick
M2.57m (8'5") -
Bucket
XD 4.4 m³ (5.75 yd³)
-
Track Gauge
3410 mm
-
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom
7080 mm -
Bucket Digging Force - ISO
405 kN -
Stick Digging Force - ISO
352 kN
