CAT 3512 Offshore Production Fire Pump Engine
Cat 3512 Diesel Fire Pump Engine. Ratings: 1066-1193 bkW (1430-1600 bhp) @ 1460-1750 rpm are non-certified, not FM Approved, not UL Listed. They are available for global non-regulated areas.
Share
Overview
Cat 3512 Diesel Fire Pump Engine. Ratings: 1066-1193 bkW (1430-1600 bhp) @ 1460-1750 rpm are non-certified, not FM Approved, not UL Listed. They are available for global non-regulated areas.
-
Minimum Rating
1066.0 bkW -
Maximum Rating
1195.0 bkW
-
Emissions
Non-certified -
Rated Speed
1460.0 RPM -
Bore
170.0 mm -
Stroke
190.0 mm -
Displacement
51.8 L -
Aspiration
Turbocharged Aftercooled
-
Engine Specifications
6360.0 kg -
Flywheel and Flywheel Housing
SAE No. 0 -
Flywheel Teeth
151
-
Rotation (from flywheel end)
Counterclockwise
-
Lube Oil System (refill)
160.0 L -
Cooling System (engine only)
318.0 L
-
Length
2890.0 mm
-
Width
1744.0 mm
-
Height
1902.0 mm
