SEM 824F Motor Grader

824F features the new F series design and is powered by the Weichai WD12 T2 engine, delivering a gross power of up to 185 kW (248 hp). The machine utilizes an electronically controlled hydrostatic transmission system, enhancing productivity and maneuverability. It offers various track shoe widths from 560 mm to 915 mm and multiple blade options, including SU, S, U, Waste Handling, and Forest blades. Rear equipment options include multi-shank ripper, single shank ripper, and winch to meet diverse customer needs.

Get a Quote Download Brochure

Overview

824F features the new F series design and is powered by the Weichai WD12 T2 engine, delivering a gross power of up to 185 kW (248 hp). The machine utilizes an electronically controlled hydrostatic transmission system, enhancing productivity and maneuverability. It offers various track shoe widths from 560 mm to 915 mm and multiple blade options, including SU, S, U, Waste Handling, and Forest blades. Rear equipment options include multi-shank ripper, single shank ripper, and winch to meet diverse customer needs.

Engine

Rated Speed
2,100 r/min
Gross Power - ISO 14396
185 kW/248 hp
Model
WD12G250E202

Hydraulic System

Type
Gear Pump, Pilot control
Implement Hydraulic System Pressure
19 MPa

Blade

Blade Type
SU/S

Model

Operating Weight
23,730 kg
Ground Pressure
63 kPa
Ground Clearance
400 mm
Max.Slope
30°

Powertrain

Type
Dual-path, closed loop electronically controlled hydrostatic drive system
Travel Speed-F/R
Infinitely variable speeds 0-10 km/h
Steering & Brake
Hydrostatic steering; wet, multi-disc brake, Bellville spring actuated and hydraulically released
