Hindustan Wheel Loader 2021F

The Hindustan 2021F Small Wheel Loaders set the standard for productivity, fuel efficiency and operator comfort. The improved optimized Z-bar loader linkage delivers the quick loading performance of traditional Z-bar with the parallelism and load handling capability of a tool carrier. Expect high fill factors and reduced fuel consumption per unit with the Hindustan 2021F Wheel Loader. Increased lift height facilitates faster and easier loading. With extended service intervals, you can enjoy more productive time on the job and less downtime.

Get a Quote Download Brochure

Overview

The Hindustan 2021F Small Wheel Loaders set the standard for productivity, fuel efficiency and operator comfort. The improved optimized Z-bar loader linkage delivers the quick loading performance of traditional Z-bar with the parallelism and load handling capability of a tool carrier. Expect high fill factors and reduced fuel consumption per unit with the Hindustan 2021F Wheel Loader. Increased lift height facilitates faster and easier loading. With extended service intervals, you can enjoy more productive time on the job and less downtime.

Engine

Rated Power
98 kW (133hp) @ 2300 RPM
Max Torque
475 Nm @ 1400 - 1900 rpm

Transmission

Reverse 1
9.5 kmph
Type
Powershift transmission with mechanically actuated hydraulic control
Forward 1
7.0 kmph
Forward 2
24.3 kmph

Tires

Size
14.00 x 25 - 20 PR E3/L3

Brakes

Service brake
4 Wheel air actuated brakes with separate circuit for front & rear
Parking brake
Mechanically expanding shoe brake mounted at transmission output shaft
Emergency brake
4 Wheel air actuated brakes with one circuit for front & rear

Engine Specifications

Engine Model
Ashok Leyland / H6C513323, Bharat Stage V (CEV) Complaint Engine

Drive Axles

Type
4 WD with Conventional heavy duty differential with planetary hub reduction
Rear axle oscillation
+/- 11 deg

Main Specifications

Bucket Capacity
1.53 - 3.0 m^3
